Zhongke controllable R6440H0 Haiguang processor storage backup type 4U dual-socket rackmount domestic server

基本概述

中科可控 R6440H0 是一款高性能的 4U 双路机架式服务器，适用于多种企业级应用场景，为企业提供了强大的计算能力、大容量存储和可靠的稳定性12。

硬件配置

• 处理器：搭载 2 颗海光 S316 2.4G/16C 处理器，具有出色的并行处理能力，能同时处理多个复杂任务，满足企业在大数据处理、虚拟化等方面的需求3。
• 内存：采用 ECC 内存，具有纠错功能，能有效提高数据的准确性和稳定性。总内存容量可达到 256GB，为系统的流畅运行和数据的快速处理提供了充足的空间1。
• 存储：支持 RAID 5 磁盘阵列，提供了数据冗余和容错能力，确保数据的安全性。配备 2 块 960G SSD 和大容量机械硬盘，可满足企业对不同存储需求3。
• 显卡：集成显卡控制器，最大分辨率 1920x1080，可满足基本的显示需求14。
• 散热与电源：散热方面，配备 4 个热插拔风扇模组，能够有效降低服务器的温度，确保服务器在高负载运行时的稳定性。电源采用 1+1 冗余设计，当一个电源出现故障时，另一个电源可以继续为服务器供电，保证服务器的正常运行14。

软件兼容性

支持多种主流操作系统，如方德高可信服务器操作系统、银河麒麟高级服务器操作系统、统信服务器操作系统、大云企业操作系统（BC-Linux）、凝思安全操作系统、欧拉开源操作系统（openEuler）、龙蜥操作系统 Anolis OS、Microsoft Windows Server、Red Hat Enterprise Linux、SUSE Linux Enterprise Server、CentOS、VMware ESXi、Ubuntu Server、Oracle Enterprise Linux 等14。

接口与扩展

• 网络接口：配备双口 1G PCIe RJ45 网卡、双口 10G PCIe 多模光纤网卡2 和双口 25G PCIe 多模光纤网卡2，满足不同网络环境和带宽需求14。
• 其他接口：提供 1 个 RJ-45 管理接口和 1 个 VGA 接口，位于机箱后部，4 个 USB 接口，2 个位于机箱后部、2 个位于机箱前部，可选 1 个串口，位于机箱后部，方便用户进行管理和设备连接14。

服务与支持

• 售后保障：提供全国联保服务，质保期为三年，让用户无后顾之忧3。
• 出货速度：最快出货时间为 2 天，能快速满足用户的需求3。
• 代理加盟：支持代理加盟，为经销商提供了良好的合作机会3。

以下是其对应的英文介绍：

Basic Overview

The Zhongke Kekong R6440H0 is a high-performance 4U dual-socket rack-mounted server applicable to a variety of enterprise-level application scenarios, providing enterprises with powerful computing capabilities, large-capacity storage, and reliable stability [1,3].

Hardware Configuration

• Processor: It is equipped with two Hygon S316 2.4G/16C processors, which have excellent parallel processing capabilities and can handle multiple complex tasks simultaneously to meet the needs of enterprises in big data processing, virtualization and other aspects [5].
• Memory: It adopts ECC memory with error correction function, which can effectively improve the accuracy and stability of data. The total memory capacity can reach 256GB, providing sufficient space for the smooth operation of the system and the rapid processing of data [1].
• Storage: It supports RAID 5 disk array, which provides data redundancy and fault tolerance to ensure data security. It is equipped with 2 960G SSDs and large-capacity mechanical hard disks to meet the different storage needs of enterprises [5].
• Graphics Card: The integrated graphics controller has a maximum resolution of 1920x1080, which can meet the basic display needs [1,7].
• Cooling and Power Supply: In terms of cooling, it is equipped with 4 hot-swappable fan modules, which can effectively reduce the temperature of the server and ensure the stability of the server under high-load operation. The power supply adopts 1+1 redundant design. When one power supply fails, the other power supply can continue to power the server to ensure the normal operation of the server [1,7].

Software Compatibility

It supports a variety of mainstream operating systems, such as Fangde High Trust Server Operating System, Galaxy Kirin Advanced Server Operating System, UnionTech Server Operating System, Dayun Enterprise Operating System (BC-Linux), Ningsi Secure Operating System, Euler Open Source Operating System (openEuler), Anolis OS, Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, VMware ESXi, Ubuntu Server, Oracle Enterprise Linux, etc. [1,7].

Interface and Expansion

• Network Interface: It is equipped with a dual-port 1G PCIe RJ45 network card, two dual-port 10G PCIe multimode fiber network cards and two dual-port 25G PCIe multimode fiber network cards to meet the needs of different network environments and bandwidths [1,7].
• Other Interfaces: It provides 1 RJ-45 management interface and 1 VGA interface at the rear of the chassis, 4 USB interfaces, 2 at the rear of the chassis and 2 at the front of the chassis, and an optional 1 serial port at the rear of the chassis, which is convenient for users to manage and connect devices [1,7].

Service and Support

• After-sales Guarantee: It provides national joint warranty service with a warranty period of three years, allowing users to have no worries [5].

• Delivery Speed: The fastest delivery time is 2 days, which can quickly meet the needs of users [5].

• Agent Franchise: It supports agent franchise, providing a good cooperation opportunity for dealers [5].
